Orbbec Femto Bolt 1MP ToF Depth Camera 4K RGB HDR USB-C (Azure Kinect Alternative)

• Quick Start: https://www.orbbec.com/femto-bolt-document/
• Tips: Runs existing Azure Kinect DK applications unchanged via the Orbbec Azure Kinect Sensor SDK Wrapper (K4A Wrapper) — swap the camera, keep your code.

Introduction

The Orbbec Femto Bolt is a compact, high-performance ToF depth camera from Orbbec, co-developed with Microsoft using Microsoft's industry-proven Time of Flight (iToF) technology. It delivers depth modes and performance identical to the Microsoft Azure Kinect DK and the Orbbec Femto Mega, combined with a 4K HDR RGB camera, 6DoF IMU and a single USB 3.2 Type-C connection for both power and data. It processes on the host computer and is supported by the Orbbec SDK with an Azure Kinect Sensor SDK Wrapper for seamless software migration.

Features

• 1 Mega Pixel ToF depth sensor with 120° field of view
• Up to 15fps at 1024x1024 or 30fps at 640x576 depth resolution
• 4K RGB with HDR support
• 6DoF IMU
• USB Type-C 3.2 for power and data
• Sophisticated and accurate synchronization trigger control for multi-sensor networks
• Identical depth operating modes and performance as Microsoft Azure Kinect DK and Orbbec Femto Mega
• High resolution RGB-D in a compact form factor, with color-to-depth registration

Shipping List

• 1x Orbbec Femto Bolt depth camera


Applications

• Robotics — object detection and tracking for safer, more efficient workers; precise dimensions for mechanical arms
• Health — computer vision tracking of body movement and form with AI-driven body skeleton insights for elderly care, rehabilitation and fitness
• Media — 1MP depth plus 4K color for volumetric video in AR/XR and interactive broadcasting
• Dimension — accurate and precise package dimension measurement to improve logistics and shipping accuracy

Specification

Detailed Descriptions

• Quick-Start Development Library for a swift transition from Azure Kinect DK to Femto Bolt: Access AKDK application software with Femto Bolt (tutorial)
• Orbbec SDK (GitHub): https://github.com/orbbec/OrbbecSDK
• Azure Kinect Sensor SDK Wrapper v1.8.3: https://github.com/orbbec/OrbbecSDK-K4A-Wrapper/releases/tag/v1.8.3
• Azure Kinect Body Tracking demos (Unity): https://github.com/orbbec/Azure-Kinect-Samples/tree/master/body-tracking-samples/sample_unity_bodytracking
• Documentation hub: https://www.orbbec.com/femto-bolt-document/
• 2D and 3D CAD files (GitHub): https://github.com/orbbec/OrbbecHardware
• Femto Bolt vs Azure Kinect DK comparison: https://www.orbbec.com/documentation/comparison-with-azure-kinect-dk/
