Industrial PROFINET to Modbus RTU Gateway,RS232/RS485, Master/Slave Support
$847.00
Shipping calculated at checkout.
Couldn't load pickup availability
You may also like
CYXK Industrial Protocol Gateways
5-Product Parameter Comparison Table & Selection Matrix (copy-paste ready for Taobao / product page)
| Item | CYGW-MRM-PNS-1 CY001 |
CYGW-MRM-PNS-3 CY003 |
CYGW-COM-PNS CY005 |
CYGW-COM-ECS CY035 |
CYGW-PNM-ECS CY405 |
|---|---|---|---|---|---|
| Model | CY001 | CY003 | CY005 | CY035 | CY405 |
| Protocol / Interface | |||||
| Uplink Protocol | PROFINET V2.3 | PROFINET V2.3 | PROFINET V2.3 | EtherCAT DS301 V4.022 | PROFINET V2.4 Master |
| Downlink Protocol | Modbus RTU V1.1b3 | Modbus RTU V1.1b3 | CANopen DS301 v4.0.2 | CANopen DS301 v4.0.2 | EtherCAT ETG.1000 Slave |
| Ethernet Port | 2×100M RJ45 (integrated switch) |
2×100M RJ45 (integrated switch) |
2×100M RJ45 (integrated switch) |
IN+OUT 2×100M RJ45 (integrated switch) |
Dual 100M RJ45 |
| Serial / CAN Port | 1×RS232/ RS485 selectable |
3×RS485 terminal | 3×CAN terminal | 3×CAN terminal | EtherCAT IN/OUT |
| Downlink Node Count | 32 RTU slave | 96 RTU slave (32 per port) |
96 CAN nodes (32 per port) |
384 CAN nodes (128 per port) |
128 PN slaves |
| Process Data Capacity | 1440B IN + 1440B OUT |
1440B IN + 1440B OUT |
128 TPDO + 128 RPDO |
128 RPDO + 128 TPDO |
1.5MB IN + 1.5MB OUT |
| Protocol Conversion Latency | <1ms | <15ms | <15ms | — | <100μs |
| Redundancy Protocol | MRP / IRT / FSU | MRP / IRT / FSU | MRP / IRT | — | Not supported |
| Configuration Tools | |||||
| Config Interface | Mini USB | Mini USB | Mini USB | Ethernet CFG port | Ethernet / PNM/CFG |
| Config Software | Configuration Tool | Configuration Tool | CANopen Manager | CANopen Configuration Studio | PN Master Config Tool (WIN7/10/11) |
| Language | CN / EN switchable | CN / EN switchable | CN / EN switchable | CN / EN switchable | CN / EN switchable |
| Electrical / Environment | |||||
| Power Supply | 24V DC ±10% 100mA typ |
24V DC ±10% 130mA typ |
24V DC ±10% 130mA typ |
24V DC ±10% 130mA typ |
20~40V DC 198mW@24V |
| Isolation Protection | Triple isolation reverse/short-circuit |
Triple isolation reverse/short-circuit |
Triple isolation reverse/short-circuit |
Triple isolation reverse/short-circuit |
IP20 |
| Protection Rating | IP20 | IP20 | IP20 | IP20 | IP20 |
| Enclosure / Size / Weight | Full metal 34×110×74mm ~330g |
Full metal 34×110×74mm ~330g |
Full metal 34×110×74mm ~330g |
Full metal 34×110×74mm ~330g |
Full metal 34×110×74mm ~330g |
| Mounting | DIN 35mm rail | DIN 35mm rail | DIN 35mm rail | DIN 35mm rail | DIN 35mm rail |
| Operating Temp. | -20°C ~ +70°C | -20°C ~ +70°C | -20°C ~ +70°C | -20°C ~ +70°C | -20°C ~ +70°C |
| Storage Temp. | -40°C ~ +85°C | -40°C ~ +85°C | -40°C ~ +85°C | -40°C ~ +85°C | -40°C ~ +85°C |
| Quick Application Reference | |||||
| One-line Positioning | Connect Modbus devices to Siemens PROFINET |
High-density multi-Modbus to PROFINET |
Connect CANopen devices to PROFINET |
Connect CANopen devices to EtherCAT motion control |
Cross-bus hub: PROFINET master controls EtherCAT slaves |
| Typical Industries | Metallurgy / Building / Petrochem | Metallurgy / Building / AGV | Automotive / New Energy | Semiconductor / CNC | Automotive / Semiconductor / Retrofit |
CYXK Gateway Selection Matrix — Full Series Model Reference
Find the matching model at the intersection based on your PLC protocol (row) and field-device protocol (column). The 5 on-shelf models are highlighted in red.
| PLC ↓ / Device → | X Series: connect simple-interface devices to PLC | |||||
|---|---|---|---|---|---|---|
| Modbus RTU | FreeCom-3 | Modbus RTU-3 | Modbus TCP | CANopen Master | FreeCAN | |
| PROFINET Slave | CY001 ★ | CY002 | CY003 ★ | CY004 | CY005 ★ | CY006 |
| EtherNet/IP Slave | CY011 | CY012 | CY013 | CY014 | CY015 | CY016 |
| PROFIBUS DP Slave | CY021 | CY022 | CY023 | CY024 | CY025 | CY026 |
| EtherCAT Slave | CY031 | CY032 | CY033 | CY034 | CY035 ★ | CY036 |
| Modbus TCP Slave | CY041 | CY042 | CY043 | CY044 | CY045 | CY046 |
| CANopen Slave | CY051 | CY052 | CY053 | CY054 | CY055 | CY058 |
| Modbus RTU Slave | CY061 | CY062 | CY063 | CY064 | CY065 | CY066 |
| CC-Link IE FB Slave | CY071 | CY072 | CY073 | CY074 | CY075 | CY076 |
| CC-Link Slave | CY081 | CY082 | CY083 | CY084 | CY085 | CY086 |
| DEVICENET Slave | CY091 | CY092 | CY093 | CY094 | CY095 | CY096 |
| CC-Link IE TSN Slave | CY0A1 | CY0A2 | CY0A3 | CY0A4 | CY0A5 | CY0A6 |
| PLC ↓ / Device → | Y Series: connect complex-interface devices to PLC | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| PROFINET Slave | Modbus RTU Slave | Modbus TCP Slave | EtherNet/IP Slave | PROFIBUS DP Slave | EtherCAT Slave | CC-Link IE TSN Slave | CANopen Slave | ||
| PROFIBUS DP Master | CY100 | CY101 | CY102 | CY103 | CY104 | CY105 | CY106 | CY107 | CY108 |
| EtherNet/IP Master | CY200 | CY201 | CY202 | CY203 | CY204 | CY205 | CY206 | CY207 | CY208 |
| EtherCAT Master | CY300 | CY301 | CY302 | CY303 | CY304 | CY305 | CY306 | CY307 | CY308 |
| PROFINET Master | CY400 | CY401 | CY402 | CY403 | CY404 | CY405 ★ | CY406 | CY407 | CY408 |
| DEVICENET Master | CY500 | CY501 | CY502 | CY503 | CY504 | CY505 | CY506 | CY507 | CY508 |
| CC-Link IE TSN Master | CY600 | CY601 | CY602 | CY603 | CY604 | CY605 | CY606 | CY607 | CY608 |
| CC-Link IE Basic Field Master | CY700 | CY701 | CY702 | CY703 | CY704 | CY705 | CY706 | CY707 | CY708 |
| CC-Link Master | CY800 | CY801 | CY802 | CY803 | CY804 | CY805 | CY806 | CY807 | CY808 |
