IMX179 8MP UVC Camera, 4P 1.25/1.5/2.0mm connector, Autofocus, Without Microphone, Without IR
  • IMX179 8MP UVC Camera, 4P 1.25/1.5/2.0mm connector, Autofocus, Without Microphone, Without IR
  • IMX179 8MP UVC Camera, 4P 1.25/1.5/2.0mm connector, Autofocus, Without Microphone, Without IR
  • IMX179 8MP UVC Camera, 4P 1.25/1.5/2.0mm connector, Autofocus, Without Microphone, Without IR
  • IMX179 8MP UVC Camera, 4P 1.25/1.5/2.0mm connector, Autofocus, Without Microphone, Without IR
IMX179 8MP UVC Camera, 4P 1.25/1.5/2.0mm connector, Autofocus, Without Microphone, Without IR

IMX179 8MP UVC Camera, 4P 1.25/1.5/2.0mm connector, Autofocus, Without Microphone, Without IR

Vendor: youyeetoo
SKU: FHLPJIMX1792
Availability: In stock
$284.00
Shipping calculated at checkout.
Model: ZV-A016-V2
Product subtotal: $284.00

You may also like
Parameter ZV-A016-V2
Module Model ZV-A016-V2
Resolution 8 Mega (3264x2448)
Sensor Type 1/3.2inch
Max Effective Pixels 8 Mega pixels
Pixel Size 1.4μm × 1.4μm
Max Dynamic Range Auto
Max SNR /
Gain/Exposure/White Balance Auto
Resolution & Max Frame Rate MJPG: 3264x2448@15fps, 2592x1944@20fps, 1920x1080@30fps, 1280x960@30fps, 1280x720@30fps, 640x480@30fps, 176x144@30fps; YUY2: 3264x2448@2fps, 2592x1944@2fps, 1920x1080@5fps, 1280x960@5fps, 1280x720@10fps, 640x480@30fps, 176x144@30fps
Max Working Current MAX 1.2W, Current 180mA-230mA
Interface Type USB2.0 (A port) +4P 1.25/1.5mm DIP
Microphone IIC Supports Digital IIC
Focus Type -
Power Supply Voltage USB_5V±5%
Lens Type 1/3 inch
Lens Structure 5P
Aperture F/NO 2.4 (varies, consult customer service)
EFL Effective Focal Length 3.5mm
Field of View (FOV) Diagonal D=78°, Horizontal H=66°, Vertical V=52° (consult customer service for others)
Distortion <1.0%
Filter 650 Visible Light, etc. (selected according to buyer's needs)
PCB Size 32.00×32.00×1.6mm
Module Size 32.00mm×32.00mm×6.8mm
Operating Temperature -30~70℃
Stable Imaging Temperature /
Storage Temperature -10~65℃
Camera Board Assembly Technology SMT (ROHS)
Operating System WindowsXP/7/8/10/vista/Server/Linux (include UVC)/Android/ raspberry /mac OS/RTOS/Vista/Ubuntu, etc.
Application Devices Smart Home, Computer and Peripherals, New Media Entertainment, Security Monitoring, Medical Health, Internet of Things, Vehicle, Industrial Detection and Automation, Education/Live Broadcasting, AI Vision, Intelligent Transportation Terminals, Robots/Unmanned Aerial Vehicles, Advertising Machines, Self-Service Devices, All-in-One Machines, Driving Recorders, etc.

2. Product Dimensions

  • Overall Size: 32±0.2mm (length) × 32±0.2mm (width)
  • Side View: 6.8±0.2mm (macro state height), 6.6±0.2mm (body height), 6.4±0.2mm (total module height)
  • Optical Parameters: 78°(macro), 73°(φ4), 1.35mm (lens projection), 4.6±0.1mm (interface height), 3.5mm (interface length)

3. Key Features

  • Industrial-Grade Chip: Captures clear, delicate frames for vivid and realistic videos.
  • USB2.0 Interface: Standard, system-compatible, driver-free, plug-and-play, ensuring efficient data transmission and image integrity.

4. Cable Specification

  • Default Cable: Plug-in type, 1.5 meters long.
  • Customization: Welded type or cable lengths from 0.1 to 5 meters are available (consult customer service for customization).

Category Details
Product Model AX-3079-V1.0 (Corresponding to DSJ-3079-HE)
Sensor Sony IMX179
Lens Size 1/3.2inch
Pixel Size 1.4um
Image Area 6.18mm x 5.85mm
Maximum Effective Pixels 3264(H) X 2448(V) 8MP
Output Image Format MJPEG
Supported Resolutions and Frame Rates 3264X2448 @ 15fps / 2592X1944 @ 15fps
1920x1080 @ 30fps / 1600X1200 @ 30fps
1280x720 @ 30fps / 960X540 @ 30fps
800X600 @ 30fps / 640X480 @ 30fps
Signal-to-Noise Ratio (SNR) 34dB
Dynamic Range 72.5dB
Sensitivity 0.65V/lux-sec@550nm
Minimum Illumination 0.5lux
Shutter Type Electronic rolling shutter / Frame exposure
Interface Type USB2.0 High Speed
Supported Driver-Free Protocol USB Video Class (UVC)
Supported OTG Protocol USB2.0 OTG
Automatic Exposure Control (AEC) Supported
Automatic White Balance (AEB) Supported
Automatic Gain Control (AGC) Supported
Button Capture Supported
Adjustable Parameters Brightness, Contrast, Saturation, Hue, Sharpness
Gamma, Gain, White Balance, Reverse Contrast, Exposure
Lens Parameters High-Speed Camera Lens, No Distortion, Size 1/3.2
Auto Focus, 75 Degrees
Fill Light Electrical Interface Supported, 4P-2.0 Socket
Power Supply Mode USB BUS POWER, 4P-2.0mm Socket
Operating Voltage DC5V
Operating Current 160mA~260mA
Operating Temperature -10~70℃
Storage Temperature -20~85℃
Board Size 38x38mm (Compatible with 32X32mm)
Supported Systems WinXP/Vista/Win7/Win8
Linux with UVC (above linux-2.6.26)
MAC-OS X 10.4.8 or later
Wince with UVC
Android 4.0 or above with UVC
