Nanopi R2S PLUS

mini-router with edge-computing and dual Gbps Ethernet ports

5V3A PSU : https://www.youyeetoo.com/products/5v-3a-power-supply-adapter

Hardware Spec

• CPU: Rockchip RK3328, Quad-core Cortex-A53
• DDR4 RAM: 1GB
• Flash: 32GB eMMC 5.1 Flash
• Network：

  1 x Internal 10/100/1000M Ethernet
  1 x USB 3.0 converted 10/100/1000M Ethernet
  Optional M.2 SDIO Wi-Fi


• 2 x USB 2.0 Host Type-A
• 1 x microSD Slot
• USB-C Power: 5V power input and USB update in maskrom mode
• USB-C Bebug: onboard USB to Debug UART converter, 1500000bps bauds
• 3 x LED, for WAN, LAN and SYSTEM
• 1 x GPIO Button, 1 x Maskrom mode button
• PCB Size: 58*58*1.6mm
• Power Supply: DC 5V/2A
• Temperature measuring range: 0℃ to 70℃
• OS/Software: U-boot，Ubuntu-Core，OpenWrt

• Network Transmission Rates

TXRXWAN941 Mbps941 MbpsLAN941 Mbps941 MbpsNotes：1. test utility: iperf2. use indepedent IP address section and test with a PC in simplex communication mode
