BPI-R4 Router board - Support WIFI 7 Model
Introduction
Banana Pi BPI-R4 Router board with MediaTek MT7988A (Filogic 880) quad-core ARM Corex-A73 design,4GB DDR4 RAM,8GB eMMC,128MB SPI-NAND flash onboard, also have 2x 10Gbe SFP, 4x Gbe network port, with USB3.2 port, M.2 support 4G/5G/NVME SSD.2x miniPCIe slots with PCIe3.0 2lane interface for Wi-Fi 7 NIC (Network Interface Card). It is a very high-performance open-source router development board.
MediaTek MT7988(Filogic 880)
Mediatek Filogic 880. the 36Gbps Wi-Fi 7 access point/router/gateway platform delivers the fastest and most reliable connection experience
The MediaTek MT7988A is a world-leading network processing platform for high-performance and reliable networking experiences, both in wired and wireless applications. The MT7988A comprises a rich connection interface set including 4 Gigabit Ethernet ports. 2 US下GMII interfaces. 4 PCIe Interfaces, and 2 USB 3.2 en1 Ports
the MT7988A further enables seamless Wi-Fi 7 tri-band,2.4 GHz.5 GHz and 6 GHz, connectivity, with its Wi-Fi 7 companion chip that features 320-MHz bandwidth,4096-QAMLO, MCU,and FC.
To answer the need of first-evolving tunneling applications, the MT7988A comes with MediaTek Tunnel offload processor System(TOPS), which facilitates the processing of a wide range of tunneling protocols. The MT7988A optimizes networking performance with the exquisitely tuned ISA of MediaTek TOPS and is dedicated to lifting networking offloading performance to premium level.
Features
- MediaTek MT7988A (Filogic 880) quad-core Arm Corex-A73,1.8GHz processor
- 4GB DDR4
- 8GB eMMC flash
- 128MB SPI-NAND Flash
- Micro SD card slot
- 2x 10Gbe SFP slot (option 1x 10GbE SFP and 1x SOC embedded 2.5GbE PHY. NOTE: Need to modify hardware)
- 4x Gbe network port
- 1x USB3.2 slot
- 1x M.2 KEY-B slot with USB3.2/PCIe3.0 interface for 5G
- 1x M.2 KEY-M slot with PCIe3.0 1lane interface for NVME SSD
- 2x mini PCIe slots with PCIe3.0 2lane interface for Wi-Fi 7 NIC (Network Interface Card)
- 26 PIN GPIO Header for expanding application
Shipping List
- Only Board: BPI-R4 Router board X1
- Power Kit: BPI-R4 Router board X1, 12V3A DC Power x1, Debug module x1
- WIFI 7: WIFI 7 module x1, Antenna x6
- 12V5A : Only 12V5A DC Power x1
- Metal Kit : BPI-R4 Metal Case x1
- Cooling Fan: Cooling Fan x1
- R4 POE Version Kit: BPI-R4 Router board X1, Cooling Fan x1
Applications
- Internet service Router
- Wifi 7 Wireless Router
- 4G/5G Wireless Router
- Wireless Repeater
- Home security Gateway
- Home Automation
- Nas device
- Network and communication applications
